Description
*SNOW BLADE systems @ additional cost
GO ANYWHERE … WORK HUNT PLAY…
PERFORMANCE AND BREAKTHROUGH
Blade 1000 LT EPS is equipped with an 83 HP strong V-twin engine, 4WD/2WD switchable with front/rear differential lock, unmatched higher ground clearance and 52° increased front approach angle. Blade 1000 LT EPS would definitely renew your impressions to 1000 cc ATV.
Engine Type 997 cc, V-twin, SOHC
Ignition ECU
Starter Electric
Bore X Stroke Ø 92 × 75 mm
Compression Ratio 10.2
Fuel System 50 mm Throttle Body / Programmed Fuel Injection
Max Power 83 HP / 7000 rpm
Max Torque 89.9 Nm / 5500 rpm
Drive System 4 × 4 Shaft Drive
Gear Selection L / H / N / R / P
Transmission V-Belt CVT Automatic
Engine Braking System Standard
Over Ride Button Standard
Front Suspension Dual A-arm
Rear Suspension Dual A-arm with Anti-roll Bar
Front/Rear Brake Hydraulic Disc with piston caliper and Hydraulic Foot Brake
Parking Brake Park In Transmission / Lockable Hand Lever
Front Tire AT 26 × 9 – 14 , 6 PLY
Rear Tire AT 26 × 11 – 14 , 6 PLY
Wheelbase (mm) 1460
Length/Width/Height (mm) 2340 X 1255 X 1340
Fuel Capacity 23 L
Electrical Outlet Connector 2 DC 12V 10A 120W
Instrumentation Digital instrument panel with odometer, speedmeter, Tripmeter, RPM, transmission position, fuel gauge, Hi-Temp/Low-Battery lights, high beam light, EFI checking, differential indicator, 2WD/4WD indicator, EPS indicator (adjustable power steering)
