Description
Engine and transmission
Displacement: 1851.9 ccm (113.00 cubic inches)
Engine type: V2, four-stroke
Compression: 9.5:1
Bore x stroke: 100.0 x 118.0 mm (3.9 x 4.6 inches)
Fuel system: Injection. Twin-bore electronic fuel injection, w/ 43mm throttle bodies and throttle position sensor
Ignition: Digital TCI
Cooling system: Air
Gearbox: 5-speed
Transmission type,
final drive: Belt
Chassis, suspension, brakes and wheels
Frame type: Aluminium
Front suspension: 46mm telescopic fork
Front wheel travel: 135 mm (5.3 inches)
Rear suspension: Single shock, link-type
Rear wheel travel: 109 mm (4.3 inches)
Front tire: 130/70-18
Rear tire: 190/60-17
Front brakes: Double disc
Diameter: 298 mm (11.7 inches)
Rear brakes: Single disc
Diameter: 320 mm (12.6 inches)
Physical measures and capacities
Dry weight: 343.8 kg (758.0 pounds)
Seat height: 734 mm (28.9 inches) If adjustable, lowest setting.
Overall length: 2581 mm (101.6 inches)
Overall width: 935 mm (36.8 inches)
Ground clearance: 155 mm (6.1 inches)
Wheelbase: 1715 mm (67.5 inches)
Fuel capacity: 17.03 litres (4.50 US gallons)
